140CPU67060 Modicon Quantum PLC / CPU Single Slot 80486 Processor With Mathematical

Name: 140CPU67060 Modicon Quantum PLC / CPU Single Slot 80486 Processor With Mathematical
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: 140CPU67060
Price: 210.00 USD
Availability: InStock

نام تجاری:	Schneider
شماره مدل:	140CPU67060
مقدار تولیدی:	1
قیمت:	Negotiations

اطلاعات دقیق

توضیحات محصول

اطلاعات دقیق

محل منبع:

فرانسه

نوع:

پلت فرم اتوماسیون کوانتومی مودیکون

نوع محصول یا مؤلفه:

محدب وحدت

بسامد ساعت:

266 مگاهرتز

جزئیات بسته بندی:

جعبه اصلی جدید

برجسته کردن:

Modicon Quantum PLC CPU,140CPU67060 PLC processor,Single slot 80486 PLC

140CPU67060 PLC processor

Single slot 80486 PLC

توضیحات محصول

140CPU67060 Modicon Quantum PLC / CPU Single Slot 80486 Processor With Mathematical

Product Attributes

Attribute	Value
Type	Modicon Quantum Automation Platform
Product Or Component Type	Unity Processor
Clock Frequency	266 MHz

Quick Details

SCHNEIDER ELECTRIC
MODICON
140CPU67060
UNITY HOT STANDBY PROCESSOR
W/ MULTIMODE ETHERNET
512KB
266MHZ
AVAILABLE
REBUILT SURPLUS
NEVER USED SURPLUS
Weight: 2kg

New one with one year warranty and used one with six months warranty

Specifications

Manufacturer: Modicon Quantum
Series: Quantum CPUs
Weight: 2 lb
Product or component: Unity processor
Clock frequency: 266 MHz
Number of slots: 10 | 16 | 2 | 4 | 6
Number of racks: 2 - local rack(s)
Number of distributed I/O station: 63 station(s) - 1 rack(s) - 3 distributed network(s)
Number of remote I/O station: 31 - 2 remote rack(s)
Discrete I/O number: 8000 inputs, 8000 outputs - distributed - per network | 31744 inputs, 31744 outputs - remote | Unlimited (26 slots max) - local
Analogue I/O number: Unlimited (26 slots max) - local | 500 inputs, 500 outputs - distributed - per network | 1984 inputs,1984 outputs - remote
Application specific I/O: Accurate time stamping | Counter | High-speed interrupt inputs | Serial link
Number of optional modules: 6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)
Maximum number of connections: Unlimited (AS-Interface) - local | 6 (Profibus DP) - local | 6 (Modbus Plus) - local | 6 (Ethernet TCP/IP) - local | 4 (AS-Interface) - remote | 2 (AS-Interface) - distributed | 1 (USB) | 1 (Modbus) - RS232/485 Modbus/ASCII
Integrated connection type: 1 Ethernet TCP/IP | 1 Modbus | 1 Modbus Plus | 1 USB
Checks: Process control
Memory description: Expandable 8 MB - file storage with PCMCIA card | Expandable 7168 kB - program with PCMCIA card | Internal RAM 768 kB
Switch function: Key switch memory port on/off
Application structure: 4 auxiliary tasks | 32 timer interrupt tasks | 128 interrupt tasks | 128 I/O interrupt tasks | 1 periodic fast task | 1 cyclic/periodic master task
Execution time per instruction: 0.48...0.56 µs floating points | 0.0525...0.075 µs Boolean | 0.045...0.06 µs on word | 0.045...0.06 µs on fixed-point arithmetic
Execution time for 1 K instruction: 9.91 65 % Boolean and 35 % numerical | 10.28 100 % Boolean
System overhead: 1 ms - master task | 0.2 ms - fast task
Bus current requirement: 2160 mA
Local signalling: 1 LED red for Ethernet collision | 1 LED green for Ethernet activity (COM)
Electrical connection: 1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus network | 1 connector, connector type: RJ45 for connecting Modbus bus | 1 connector, connector type: RJ45 for connecting Ethernet network | 1 connector, connector type: MT-RJ (fiber optic) for interconnecting primary and secondary PLCs (hot standby architecture)
