High Resolution Absolute Shaft Encoder , UTTAH B17TL Stepper Motor Encoder

Servo Motor Encoder Yaskawa UTTAH-B17TL for AC SERVO MOTOR SGMRV-30ANA-YR21 - Absolute 17 bit

QUICK DETAILS

1. Brand :Yaskawa
2. Model :UTTAH-B17TL
3. Place of Origin :Japan

DESCRIPTION

• Servo Motor Encoder
• Yaskawa Electric

• AC  Motor Encoder

Light-duty encoder

Includes series: TRD-MX, TRDA-2E, TRD-S, TRD-SH

A light-duty encoder is a cost-effective encoder requiring minimal load on the shaft. Ours offer the following features:

• Size 10 (1.0 inch or 25mm) or Size 15 (1.5 inch or 38mm) diameter body
• Dustproof (IP40 or IP50 ) rating
• 4mm, 6 mm or 1/4” standard shaft or 8 mm hollow shaft
• Resolution available from 100 pulses/revolution to 2500 pulses/revolution
• Open collector or line driver outputs
• Up to 200 kHz response frequency

Medium-duty encoder

Includes series: TRD-N, TRD-NH, TRDA-20, TRDA-25, TRD-NA

A medium-duty encoder is the most popular encoder we offer. The product line offers the greatest flexibility of choice while maintaining very high quality, all for a very low price. Our medium-duty encoders offer:

• Size 20 (2.0 inch or 50mm) or Size 25 (2.5 inch flange with 2.0 inch body) frames
• Dust Proof (IP50) or splash-proof (IP65) ratings
• 8 mm or 3/8” standard shaft or 8 mm hollow shaft
• Incremental or absolute (gray code) operation
• Incremental resolution available from 3 pulses/revolution to 5000 pulses/revolution
• Absolute resolution available from 32 pulses/revolution to 1024 pulses/revolution
• Open collector, Totem-pole or line driver output versions
• Up to 200 kHz response frequency
• MS connector models available

Heavy-duty encoder

Includes series: TRD-GK

A heavy-duty encoder is the most rugged encoder you can buy. Top-of-the-line bearings help maintain a service life of 12 billion revolutions. Our heavy-duty encoders offer:

• Rugged size 30 (3.0 inch or 78mm) diameter body
• Splash-proof (IP65) rating
• 10 mm standard shaft
• Incremental operation from 30 pulses/revolution to 5000 pulses/revolution
• Totem-pole output
•  Up to 100 kHz response frequency
•
