Fluke 1732 & 1734 Three-Phase Power Loggers | Energy Analyzer

نام تجاری:	Fluke
شماره مدل:	1732 و 1734
مقدار تولیدی:	1
قیمت:	Negotistical

اطلاعات دقیق

توضیحات محصول

اطلاعات دقیق

محل منبع:

OEM

جزئیات بسته بندی:

جعبه جدید اورجینال

توضیحات محصول

Fluke 1732 & 1734 Three-Phase Power Loggers | Energy Analyzer

Accuracy Specifications

Parameters	Range	Resolution	Intrinsic Accuracy
Voltage	1000 V	0.1 V	±(0.2% + 0.01%)
Current: Direct Input i17xx-flex 1500 12"	150 A / 1500 A	0.1 A / 1 A	±(1% + 0.02%)
i17xx-flex 3000 24"	300 A / 3000 A	1 A / 10 A	±(1% + 0.03%)
i17xx-flex 6000 36"	600 A / 6000 A	1 A / 10 A	±(1.5% + 0.03%)
i40s-EL Current Clamp	4 A / 40 A	1 mA / 10 mA	±(0.7% + 0.02%)
Frequency	42.5 Hz to 69 Hz	0.01 Hz	±(0.1%)
Auxiliary Input	±10 V DC	0.1 mV	±(0.2% + 0.02%)

Electrical Specifications

Power Supply: 100 V to 500 V (measuring circuit); 100 V to 240 V (standard power cord)

Power Consumption: Maximum 50 VA

Energy Efficiency: ≥ 68.2%

Battery: Lithium-ion, 3.7 V, 9.25 Wh (customer replaceable)

Operating Time: 4 hours standard, up to 5.5 hours power-saving mode

Charging Time: < 6 hours

Data Acquisition & Storage

Resolution: 16-bit synchronous sampling

Sampling Frequency: 10.24 kHz at 50/60 Hz

Input Signal Frequency: 42.5 to 69 Hz

Wiring Types: 1-φ, 1-φ IT, split phase, 3-φ delta, 3-φ wye, 3-φ wye IT, 3-φ wye balanced, 3-φ Aron/Blondel, 3-φ open delta, current only

Memory Capacity: Typical: 10 recording sessions of 8 weeks each with 1-minute intervals

Input Specifications

Voltage Input: 4 channels (three-phase and neutral), 1000 Vrms CAT III/600 V CAT IV

Current Input: 3 channels, automatic sensor mode selection

Auxiliary Inputs: 2 channels, 0 to ±10 V DC

Wireless Connectivity: 2 channels for Fluke Connect® 3000 Series modules

Environmental Specifications

Operating Temperature: -10 °C to +50 °C (14 °F to 122 °F)

Storage Temperature: -20 °C to +60 °C (-4 °F to 140 °F)

Operating Humidity: 10% to 95% RH (temperature dependent)

Operating Altitude: 2000 m (up to 4000 m with reduced voltage category)

Enclosure Rating: IP50

General Specifications

Display: 4.3-inch Active Matrix TFT, 480 x 272 pixels, Resistive Touchscreen

Warranty: Instrument and Power Supply: 2 years; Accessories: 1 year

Calibration Cycle: 2 years

Dimensions: Instrument: 19.8 x 16.7 x 5.5 cm (7.8 x 6.6 x 2.2 in)

Weight: Instrument: 1.1 kg (2.5 lb); Power Supply: 400 g (0.9 lb)

Tamper Protection: Anti-theft lock slot

i17xx-flex 1500 12 Flexible Current Probe

Measurement Range: 1 to 150 A AC / 10 to 1500 A AC

Lossless Current: 100 kA (50/60 Hz)

Inherent Error: ±0.7% of reading

173x + iFlex Accuracy: ±(1% of reading + 0.02% of range)

Operating Voltage: 1000 V CAT III, 600 V CAT IV

Probe Cable Length: 305 mm (12 in)

Weight: 115 g

Warranty: 1 year

Reference conditions: Environment: 23 °C ±5 °C, instrument operating for at least 30 minutes, no external electric/magnetic field, RH <65%. Input conditions: CosΦ/PF=1, sinusoidal signal f=50 Hz/60 Hz.
